Puzzi 10/1

Karcher Puzzi 10/1

Name: Puzzi 10/1
SKU: 1.100-132.0
Price: 549.00 GBP
Availability: InStock

SKU: 1.100-132.0

Availability: In Stock

Exc VAT £457.50 Inc VAT £549.00

More Views

Qty:

-OR-

Spray-extraction cleaner for commercial or domestic use. With a large tank for cleaning fluid, as well as the ample water flow and pressure rates - are designed for basic cleaning of medium-sized surfaces. TheKarcher Puzzi 10/1 is the replacement model for theKarcher Puzzi 100.

Key Features:
9 litre dirt water tank:

Removable, easy to carry and empty

Accessory holder on the grip (floor nozzle resp. hand nozzle):

Comfortable transportation, tidy storage

Compact housing made of robust polypropylene plastic with grip:

Shockproof, unbreakable, rust-proof, lightweight, easy to carry

Exchangeable fan protection filter:

Fan is protected from damage caused by dirt

Safe, dry running oscillating piston pump:

High performance, maintenance-free, trouble-free

Tested, continuous running, two-stage bypass suction fan:

High performance revertive suction power, little residual moisture

Transparent suction dome:

Control of the revertive suction power

T_?V/GS approval, national and international check release:

High safety and quality standard

Two push buttons for spraying and vacuuming:

Easy handling

Removable rubber-mounted pump/fan module:

Service-friendly, easy exchange, very quiet

Two wheels and two castors

Details

The freshwater tank with filter element allows for long periods of operation and protects the pump from soiling. The robust, compact housing made of durable plastics makes the unit lightweight and easy to carry. Two large wheels and two castors for excellent manoeuvrability. Push buttons for spraying and vacuuming mode are conveniently positioned on top of the unit. Easily removable, transparent suction dome enables the checking of recovery performance at a glance. Service friendly, rubber-mounted pump and fan module. The 9 Litre dirt water tank is simply detachable.

Additional

application

For medium sized areas in commercial and private applications .

features

9 litre dirt water tank:

Removable, easy to carry and empty

Accessory holder on the grip (floor nozzle resp. hand nozzle):

Comfortable transportation, tidy storage

Compact housing made of robust polypropylene plastic with grip:

Shockproof, unbreakable, rust-proof, lightweight, easy to carry

Exchangeable fan protection filter:

Fan is protected from damage caused by dirt

Safe, dry running oscillating piston pump:

High performance, maintenance-free, trouble-free

Tested, continuous running, two-stage bypass suction fan:

High performance revertive suction power, little residual moisture

Transparent suction dome:

Control of the revertive suction power

T_?V/GS approval, national and international check release:

High safety and quality standard

Two push buttons for spraying and vacuuming:

Easy handling

Removable rubber-mounted pump/fan module:

Service-friendly, easy exchange, very quiet

Two wheels and two castors

technical

Max. Area Performance (m²/h)	20 - 25
Air flow (l/s)	74
Vacuum (mbar/kPa)	220 / 22
Spray rate (l/min)	1
Spray pressure (bar)	1
Fresh/dirty water tank (l)	10 / 9
Power rating fan (W)	1250
Power rating, pump (W)	40
Current type (V)	230 - 240
Weight without accessories (kg)	10.7
Weight incl. packaging (kg)	16.1
Dimensions (L × W × H) (mm)	705 x 320 x 435
